Oracle FS1-2 - Figure 26: Controller Slide Rails Unlocked; Figure 27: Mounting Bracket Release Button

Figure 26: Controller slide rails unlocked
Legend
1 Slide rail assembly
2 Slide rail lock buon
2 Inspect the aached cables for any binding or kinks.
3
Verify that the CMA extends fully and does not bind in the slide rails.
4 When the Controller is fully extended out, release the mounting bracket
release buon.
Figure 27: Mounting bracket release button
Oracle FS1–2 Global Procedures
59
