Oracle FS1-2

Figure 147: Pilot position during component replacement
Legend
1 Rack
2 Pilot chassis
3 Pilot rails
2 Slide the Pilot chassis fully forward until the slide lockout release tabs lock
into position.
Figure 148: Pilot
slide lockout release tabs
Pilot Replacement Procedures
179
