Figure 41: Rail-location pegs and a square-hole rack
Legend
1 Rail-location pegs 2 Cage nut
6 Extend the rail length towards the back of the rack and into the rail holes at
the back of the rack.
Figure 42: Rail extended to holes in the back of the rack
Oracle FS1–2 Global Procedures
74
