Legend
1 Slide rail
2 Mounting bracket release buon
3 Mounting bracket
Figure 17: Slide rail middle section unlocked
Legend
1 Slide rail
2 Metal lever
Tip: Press the metal lev
er on the middle section of the slide rail to unlock
the slide rail, and then push the middle section back into the rack.
3 Aach a mounting bracket to the right side of the Controller chassis.
Oracle FS1–2 Global Procedures
50
