The following table provides the maximum dimensions of an Oracle Flash
Storage System that is fully integrated at the factory in the supported Oracle rack
with Oracle PDUs.
Table 17: Maximum physical dimensions of an Oracle Flash Storage System
Component Oracle Flash Storage System
Height
42U or 1998 mm (78.7 in)
Width
600 mm (23.6 in)
Depth (front door handle to back door handle)
1200 mm (47.2 in)
Depth (doors removed)
1112 mm (43.8 in)
Maximum weight
696.6 kg (1535.7 lb)
Note: The w
eight of an Oracle Flash Storage System depends on the distribution
of Drive Enclosures in the rack and whether any Replication Engines are
included, as well as the Pilots and Controllers.
Related Links
Component Chassis Hardware Specications
PDU Hardware Specications
System Power Requirements
System Packaging and Transportation
System Environmentals
Component Chassis Hardware Specifications
The following tables provide information on the hardware specications and the
power characteristics of the Pilot, Controller, and Drive Enclosures.
Dimensions and Weight
Table 18: Pilot dimensions and weight
Attribute Value
Height 1.68 in (4.26 cm)
Width Server chassis (not including ears): 17.19 in (43.65 cm)
Serv
er chassis (with bezel): 18.90 in (48.24 cm)
Depth (not
including power
supply handles)
29.00 in (73.66 cm)
Weight 40 lb (18.1437 kg): Weight of one Pilot.
Oracle FS System Hardware Specifications
232
