Oracle FS1-2

Figure 31: Rails for the DE2-24C Drive Enclosure
Legend
1 Left-side rail for square-hole racks 3 Round-hole racks
2 Threaded-hole racks
Related Links
Install Drive Enclosur
e Rails
Drive Enclosure Rail Kits
Drive Enclosure Rail Kits
The following table summarizes the contents of the Drive Enclosure rail kits.
Oracle FS1–2 Global Procedures
63
