Install the Rack Rails for the Controller
Prior to adding Controllers, install rails into the rack for each Controller that y
ou
plan to add.
Prerequisites:
•
Ensure that you have adequate room to work around the rack while
installing the rails and the Controller.
• Aach an electrostatic discharge (ESD) wrist strap to your wrist, and stand
on an ESD mat while replacing components.
• Ensure that you have a Phillips Number 2 screwdriver with at least a 4-inch
shaft.
• If you are installing the rails in a rack with threaded holes, make sure you
have a Torx Number 20 screwdriver.
1 Mark the rack mount hole where you plan to mount the Controller.
The Controller requires tw
o standard rack units (2U) of vertical space.
2 Remove the rails from the packaging.
3 Position the front of the left rail behind the left front rack rail.
Figure 12: Controller rack mount location
Oracle FS1–2 Global Procedures
46
