Figure 5: DE2-24P Drive Enclosure CRUs
Legend
1 Drives 4 I/O module 0
2 Power cooling module 0 5 I/O module 1
3 Power cooling module 1
The following gure shows the CRUs in the DE2-24C Driv
e Enclosure.
