Oracle FS1-2 User Manual

Figure 9: Exploded view of Pilot replaceable components
Legend
1. Pilot top cover 9 SAS HBA
2 Air bae 10 Risers
3 Baery 11 DIMMs
4 Heat sink 12 Power supplies
5 Fan modules 13 CPU
6 Front Indicator Module (FIM) 14 USB OSA ash drive
7 Energy Storage Module (ESM) for Oracle 12 Gb/s
SAS PCIe RAID HBA
that goes into PCIe slot 4
15 Motherboard
8 SAS HDDs 16 Disk backplane boards
Introduction to Oracle FS1-2 System Service Procedures
30
