Table 24: Drive Enclosure power characteristics
Power
characteristic
Value
Maximum
output pow
er
Maximum power consumption depends on the type of Drive
Enclosure (DE2-24P or DE2-24C), its size (2U/4U), and
conguration.
• 4U HDD= 376VA (4TB HDD)
• 2U SFF = 260VA (900GB SFF HDD)
• 2U SSD = 307VA (19 x 1.6TB SSD)
Frequency 50–60 Hz
Voltage range 100–240 Volts AC rated
Maximum range
selection
47–63 Hz
Maximum
inrush current
20A
PDU Hardware Specifications
The PDUs used in a not-racked Oracle FS System installation must provide
redundancy for both external
AC power source and internal AC power
distribution to the components. The PDUs must provide sucient current to
meet the sum of the requirements for the Oracle FS System components.
Oracle PDUs might be purchased for use with non-Oracle racks. The Oracle FS
System component power cords have been designed to work with vertical style
Oracle or third party PDUs. Non-Oracle PDUs must be compatible with Oracle
component power cord lengths and plug types. Non-Oracle PDUs must be
mounted in a manner such that the power cords provided by Oracle might be
used and the PDUs do not obstruct the ability to replace eld replaceable units
(FRUs) and customer serviceable units (CRUs).
While planning rack-space, ensure that adequate space is also allocated for the
PDUs, if using non-Oracle PDUs.
The following tables provide information on the various PDUs for the Oracle FS
Systems, with the assumption that there are two PDUs in each rack.
Note: The term “Ph” stands for “phase” in the above tables.
Oracle FS System Hardware Specifications
235
