Legend
1 Riser R1
2 Riser R2
3 Riser R3
Note: In the Oracle FS System, riser R1 and riser R2 do not contain any HBAs.
Only riser R3 contains the PCIe slot for the internal SAS HBA
and might need to
be replaced in case of failure.
Note: The risers can be accessed only after removing the cover over the Pilot
chassis.
Note: To replace a riser, you do not need to remove the Pilot from the rack but
extend the Pilot along the Pilot rails using the cable management arm (CMA).
Procedure Overview
1 Prepare a Pilot for Component Replacement
2 Slide Pilot to Service Position
3 Power O the Pilot
4 Open Pilot Fan Door
5 Open Pilot Top Cover
6 Remove a Riser
7 Insert a Riser
8 Close Pilot Top Cover
9 Close Pilot Fan Door
10 Slide Pilot to Rack Position
11 Connect Power Cords On the Pilot
12 Verify Component Replacement on the Standby Pilot
13 Verify Component Replacement on the Active Pilot
Related Links
Pilot Components
Prepare a Pilot for Component Replacement
1 Contact Oracle Customer Support prior to replacing a Pilot component.
Oracle Customer Support identies the failed component on the Pilot for
you.
2 From Oracle FS System Manager (GUI), navigate to System > Hardware >
Pilots and select the Pilot that contains the component that you want to
replace.
Pilot Replacement Procedures
199
