If y
ou are replacing a power supply or a fan module, you are not
required to bring the Pilot oine. The power supplies and fan
modules are hot-serviceable.
Note: You can replace one power supply without bringing the Pilot
oine, as long as the second power supply remains online and
operational.
Slide Pilot to Service Position
1 Extend the rack’s anti-tilt legs.
Figure 156: Pilot position during component replacement
Legend
1 Rack
2 Pilot chassis
3 Pilot rails
2 Slide the Pilot chassis fully forward until the slide lockout release tabs lock
into position.
Pilot Replacement Procedures
188
