Each Oracle Flash Storage System supports two types of HBA connectivity SAN
(FC or iSCSI HBA
16Gb, optical only) and NAS (10 GbE HBA). The placement of
the HBA inside the riser slot is based on the Oracle FS System conguration
option selected. All HBAs supported in the Oracle FS System are customer
replaceable units (CRUs). Replacement of an HBA requires you to bring the
Controller oine. HBAs connecting to host servers must be placed into slots 1, 4,
and 5 on the risers. HBAs connecting to Drive Enclosures must be placed into
slots 2, 3, and 6 on the risers. You must install all HBAs according to the slot
numbers listed in the following table.
HBA System type Slot number
16 Gb/s Fibre Channel (FC) SAN 1, 4, 5
6 Gb/s SAS PCIe-3, 4x4 port ALL 3, 6, 2
16 Gb/s Fibre Channel (FC) or 10GbE iSCSI universal HBA,
QLogic
SAN 1, 4, 5
Note: Replacement of the HBA
will result in a change to the world wide port
name (WWPN) of the HBA, which may require modifying the external
conguration. However, changing the SAS HBAs has no aect visible externally.
Note: If both Ethernet and FC HBA are used, insert the Ethernet HBA in the rst
slot of the riser.
Procedure Overview
1 Prepare the Component for Replacement
2 Slide Controller to Service Position
3 Remove the Controller Power Supply Cords
4 Disconnect Controller Cabling
5 Open the Controller Top Cover
6 Remove a Riser
7 Remove an HBA
8 Insert an HBA
9 Insert a Riser
10 Close the Controller Top Cover
11 Reconnect Controller Cabling
12 Complete the Component Replacement
13 Verify Controller Component Status
Related Links
Controller Components
Controller Replacement Procedures
