Table 31: Controller LED status and description (front panel) (continued)
No. LED LED color Status
3
Controller OK
LED
Green Indicates these conditions:
• O – Indicates that the system is
not running in its normal state.
System pow
er might be o. The
SP might be running.
• Steady on – Indicates that the
system is powered on and is
running in its normal operating
state. No service actions are
required.
• Standby blink: Indicates that the
system is running in standby
mode and can be quickly
returned to full function.
(200ms-On: 2800ms-O)
•
Slow blink: Indicates that a
normal but transitory activity
is taking place. Slow blinking
might indicate that system
diagnostics are running or
that the system is booting.
5
Service processor
LED
Green Indicates the state of the service
processor:
•
Slow blink: Indicates the SP
is
booting.
•
Steady: Indicates a steady
state, no service action is
required.
6
Back power
supply LED
Amber Indicates the state of the power
supplies:
•
O – Indicates a steady state,
no service action is required.
•
On – Indicates a fault with
one of the power supplies.
Oracle FS System LED Status
243
