Table 32: Controller LED status and description (back panel) (continued)
No. LED LED color Status
3
Network
management LED
•
(Left) Link
and
Activity
LED: Green
•
(Right)
Speed LED:
Green,
amber, or
OFF
Indicates these conditions:
•
Link and Activity LED:
•
On or blinking – A
link is established.
•
O – No link is
established.
•
Speed LED:
•
On or blinking –
The link is
operating as a 100-
Mbps connection.
•
O – The link is
operating as a 10-
Mbps connection.
4
Net0 to Net3 status
LEDs
•
(Left) Link
and
Activity
LED: Green
•
(Right)
Speed LED:
Amber
Indicates the state of the service
processor:
•
Link and Activity LED:
•
On or blinking – A
link is established.
•
O – No link is
established.
•
Speed LED:
•
Amber – The link
is operating as a
Gigabit connection
(1000-Mbps).
•
Green – The link is
operating as a 100-
Mbps connection.
•
O – The link is
operating as a 10-
Mbps connection
or there is no link.
Related Links
Oracle FS System LEDs
Oracle FS System LED Status
247
