Measurements
R&S
®
RTM3000
156User Manual 1335.9090.02 ─ 09
If the waveform is not active, it is activated automatically when selected as measure-
ment source.
Remote command:
MEASurement<m>:SOURce on page 518
Measure Source, Measure Source 2
Set the source waveforms for delay and phase measurement, where two sources are
required.
Remote command:
MEASurement<m>:SOURce on page 518
Delay Setup
Opens a menu to configure the delay measurement or the delay to trigger measure-
ment.
See: Chapter 8.2.4, "Delay setup", on page 157
Use Gate
Activates or deactivates the measurement gate. To set the gate, scroll down and select
Gate Setup.
Remote command:
MEASurement<m>:GATE on page 527
Statistics
Activates or deactivates the statistical evaluation for the selected measurement.
Remote command:
MEASurement<m>:STATistics[:ENABle] on page 520
Reset Statistics
Deletes the statistical results for all measurements, and starts a new statistical evalua-
tion if the acquisition is running.
Remote command:
MEASurement<m>:STATistics:RESet on page 520
Delete all Measurements
Deactivates all active measurements.
Reference Level
Automatic measurements
