Remote control commands
R&S
®
RTM3000
518User Manual 1335.9090.02 ─ 09
DTOTrigger
Time between the trigger point and a selectable edge, measured
on the middle reference level.
The edge is defined with MEASurement<m>:DELay:SLOPe
and MEASurement<m>:DELay:DIRection.
PHASe
Phase difference between two waveforms (time difference/
period * 360).
BWIDth
Burst width, the duration of one burst, measured from the first
edge to the last edge that crosses the middle reference level.
POVershoot | NOVershoot
Positive and negative overshoot of a square wave.
*RST:
PEAK
MEASurement<m>:SOURce <SignalSource>[,<SignalSource2>]
Selects one of the active signal, reference or math channels as the source(s) of the
selected measurement. Available sources depend on the selected measurement type.
Suffix:
<m>
.
1..8
Selects the measurement place.
Parameters:
<SignalSource> CH1..4 | MA1 | RE1..4 | D0..15
Waveform to be measured, required for all measurement types.
For delay and phase measurements, it is the "Measure Source".
CH1 | CH2 | CH3 | CH4
Active signal channels 1 to 4
MA1
Active math channel
RE1 | RE2 | RE3 | RE4
Active reference channels 1 to 4
D0..D15
Active digital channels D0...D15. Only available, if MSO option
R&S RTM-B1 is installed.
<SignalSource2>
None | CH1..4 | MA1 | RE1..4 | D0..15
Second source waveform, which is required for delay and phase
mesurements ("Measure Source 2").
MEASurement<m>:DELay:SLOPe <SignalSlope>,<ReferenceSlope>
Sets the edges to be used for delay measurement and delay to trigger measurement.
The associated waveforms are defined with MEASurement<m>:SOURce.
