Remote control commands
R&S
®
RTM3000
516User Manual 1335.9090.02 ─ 09
MEASurement<m>:DELay:DIRection...............................................................................519
MEASurement<m>:DELay:MARKer.................................................................................520
MEASurement<m>:STATistics[:ENABle]...........................................................................520
MEASurement<m>:STATistics:RESet...............................................................................520
MEASurement<m>[:ENABle] <State>
Activates or deactivates the selected measurement.
Suffix:
<m>
.
1..8
Selects the measurement place.
Parameters:
<State> ON | OFF
*RST: OFF
MEASurement<m>:MAIN <MeasType>
Defines the measurement type to be performed on the selected source. To query the
results, use MEASurement<m>:RESult[:ACTual]?.
Suffix:
<m>
.
1..8
Selects the measurement.
Parameters:
<MeasType> FREQuency | PERiod | PEAK | UPEakvalue | LPEakvalue |
PPCount | NPCount | RECount | FECount | HIGH | LOW |
AMPLitude | MEAN | RMS | RTIMe | FTIMe | SRRise | SRFall |
PDCYcle | NDCYcle | PPWidth | NPWidth | CYCMean |
CYCRms | STDDev | DELay | PHASe | DTOTrigger |
CYCStddev | POVershoot | NOVershoot | BWIDth
See also: Chapter 8.2.2, "Measurement types", on page 150.
FREQuency
Frequency of the signal. The result is based on the length of the
left-most signal period within the displayed section of the wave-
form of the selected channel.
PERiod
Length of the left-most signal period within the displayed section
of the waveform of the selected channel.
PEAK
Peak-to-peak value within the displayed section of the waveform
of the selected channel.
UPEakvalue
Maximum (upper) value within the displayed section of the
waveform of the selected channel.
LPEakvalue
Minimum (lower) value within the displayed section of the wave-
form of the selected channel.
Measurements
