Remote control commands
R&S
®
RTM3000
614User Manual 1335.9090.02 ─ 09
PATTern
Sets the trigger event to a serial pattern. To define the pattern,
use TRIGger:A:SPI:PATTern.
For a complete configuration of the pattern mode, you also have
to set TRIGger:A:SPI:PLENgth and TRIGger:A:SPI:
POFFset.
*RST: BSTart
TRIGger:A:SPI:PATTern <DataPattern>
Defines the bit pattern as trigger condition. The pattern length is adjusted to the num-
ber of bits defined in the pattern.
Parameters:
<DataPattern> String with max. 32 characters (4 byte + 8 bit) . Characters 0, 1
and X are allowed.
Example:
TRIG:A:SPI:PATT "0011XXXX0110"
Sets a 12bit pattern.
TRIGger:A:SPI:PLENgth <PatternLength>
Returns the number of bits in the previously defined bit pattern (TRIGger:A:SPI:
PATTern). The command can also be used to shorten a previously defined bit pattern.
Parameters:
<PatternLength> Range: 1 to 32
Increment: 1
*RST: 4
Example:
TRIG:A:SPI:PATT "0011XXXX0110"
TRIG:A:SPI:PLEN?
12
TRIG:A:SPI:PLEN 4
TRIG:A:SPI:PATT?
"0011"
TRIGger:A:SPI:POFFset <PatternBitOffset>
Sets the number of bits before the first bit of the pattern.
Parameters:
<PatternBitOffset> Number of ignored bits
Range: 0 to 4095
Increment: 1
*RST: 0
Serial bus analysis
