Remote control commands
R&S
®
RTM3000
615User Manual 1335.9090.02 ─ 09
17.11.2.4 SPI - decode results
In all BUS<b>:SPI... and BUS<b>:SSPI... commands, the suffix <b> selects the
bus.
BUS<b>:SPI:FCOunt?....................................................................................................615
BUS<b>:SPI:FRAME<n>:STATus?.................................................................................. 615
BUS<b>:SPI:FRAME<n>:STARt?.................................................................................... 615
BUS<b>:SPI:FRAME<n>:STOP?.....................................................................................616
BUS<b>:SPI:FRAME<n>:DATA:MOSI?............................................................................ 616
BUS<b>:SPI:FRAME<n>:DATA:MISO?............................................................................ 616
BUS<b>:SPI:FRAME<n>:WCOunt?.................................................................................617
BUS<b>:SPI:FRAME<n>:WORD<o>:STARt?................................................................... 617
BUS<b>:SPI:FRAME<n>:WORD<o>:STOP?....................................................................617
BUS<b>:SPI:FRAME<n>:WORD<o>:MOSI?.................................................................... 618
BUS<b>:SPI:FRAME<n>:WORD<o>:MISO?.................................................................... 618
BUS<b>:SPI:FCOunt?
Returns the number of decoded frames.
Suffix:
<b>
.
1..4
Return values:
<FrameCount> Total number of decoded frames.
Usage: Query only
BUS<b>:SPI:FRAME<n>:STATus?
Returns the overall state of the specified frame.
Suffix:
<b>
.
1..4
<n> *
Selects the frame.
Return values:
<Status> OK | INCFirst | INCLast | INSufficient
INCFirst
First frame is incomplete
INCLast
Last frame is incomplete
Usage: Query only
BUS<b>:SPI:FRAME<n>:STARt?
Returns the start time of the specified frame.
Serial bus analysis
