Remote control commands
R&S
®
RTM3000
632User Manual 1335.9090.02 ─ 09
BUS<b>:UART:BAUDrate <Baudrate>
Sets the number of transmitted bits per second.
Suffix:
<b>
.
1..4
Parameters:
<Baudrate> Range: 100 to 78.1E6
Increment: 100
*RST: 115200
Default unit: Bit
BUS<b>:UART:BITime
<BurstIdleTime>
Sets the minimal time between two data frames (packets), that is, between the last
stop bit and the start bit of the next frame.
Suffix:
<b>
.
1..4
Parameters:
<BurstIdleTime> Range: Range depends on the bus configuration, mainly on
bit rate and symbol size.
Default unit: s
17.11.4.2 UART - trigger
To configure the protocol trigger, make sure to set first:
●
TRIGger:A:TYPE to BUS
●
TRIGger:A:SOURce to SBUS1 | SBUS2
TRIGger:A:SOURce:UART............................................................................................. 632
TRIGger:A:UART:MODE.................................................................................................632
TRIGger:A:UART:PATTern.............................................................................................. 633
TRIGger:A:UART:PLENgth..............................................................................................633
TRIGger:A:UART:POFFset..............................................................................................634
TRIGger:A:SOURce:UART <UartSource>
Selects the transmitter or receiver line as trigger source.
Parameters:
<UartSource> RX | TX
TRIGger:A:UART:MODE <Mode>
Specifies the trigger mode for UART/RS-232 interfaces.
Serial bus analysis
