Remote control commands
R&S
®
RTM3000
648User Manual 1335.9090.02 ─ 09
BUS<b>:CAN:FRAMe<n>:DLCValue?
Returns the number of data bytes in the specified frame.
Suffix:
<b>
.
1..4
<n> *
Selects the frame (1...n).
Return values:
<DLCValue> Non-negative integer
Usage: Query only
BUS<b>:CAN:FRAMe<n>:IDSTate?
Returns the state of the identifier.
Suffix:
<b>
.
1..4
<n> *
Selects the frame (1...n).
Return values:
<IdentifierState> OK | UNDF
UNDF: Undefined
Usage: Query only
BUS<b>:CAN:FRAMe<n>:IDTYpe?
Returns the length of the identifier: 11 bits for CAN base frames, 29 bits for CAN exten-
ded frames.
Suffix:
<b>
.
1..4
<n> *
Selects the frame (1...n).
Return values:
<IdentifierType> ANY | B11 | B29
Usage: Query only
BUS<b>:CAN:FRAMe<n>:IDValue?
Returns the identifier of the specified frame.
Suffix:
<b>
.
1..4
Serial bus analysis
