Remote control commands
R&S
®
RTM3000
713User Manual 1335.9090.02 ─ 09
SEARch:PROTocol:ARINc:LABel:CONDition
Sets the comparison condition for label: If the pattern contains at least one X (don't
care), you can trigger on values equal or not equal to the specified value. If the pattern
contains only 0 and 1, you can also trigger on a range greater than or lower than the
specified value.
The command is relevant if SEARch:PROTocol:ARINc:CONDition is set to LABel
or LDAta.
Parameters:
<LabelCondition> EQUal | NEQual | GTHan | GEQual | LEQual | LTHan | WITHin |
OUTSide
SEARch:PROTocol:ARINc:LABel:MAXimum
Searches for a maximum value of the label if SEARch:PROTocol:ARINc:LABel:
CONDition is set to INRange or OORange.
The command is relevant if SEARch:PROTocol:ARINc:CONDition is set to LABel
or LDATa.
Parameters:
<LabelMaximum> 01X-string
SEARch:PROTocol:ARINc:LABel:MINimum
Searches for a minimum value of the label.
The command is relevant if SEARch:PROTocol:ARINc:CONDition is set to LABel
or LDATa.
Parameters:
<LabelMinimum> 01X-string
SEARch:PROTocol:ARINc:SDI
Searches for the specified source/destination identifier (SDI) bits.
The command is relevant if SEARch:PROTocol:ARINc:CONDition is set to LDATa.
Parameters:
<SDIvalue> ANY | S00 | S01 | S10 | S11
SEARch:PROTocol:ARINc:SSM
Searches for specified sign/status matrix (SSM) bits.
The command is relevant if SEARch:PROTocol:ARINc:CONDition is set to LDATa.
Parameters:
<SSMvalue> ANY | S00 | S01 | S10 | S11
Serial bus analysis
