Suffix:
<m>
.
1..3
Irrelevant, omit the suffix.
Parameters:
<Polarity> POSitive | NEGative
*RST: POSitive
Usage: Asynchronous command
TRIGger<m>:OUT:PLENgth
<PulseLength>
Sets the length of the trigger out pulse.
Suffix:
<m>
.
1..3
Irrelevant, omit the suffix.
Parameters:
<PulseLength> Range: 4E-9 to 0.06
Increment: 20E-9
*RST: 100E-9
Default unit: s
Usage: Asynchronous command
TRIGger<m>:OUT:DELay <Delay>
Sets the delay of the first pulse edge to the trigger point.
The setting is not available if a mask test or measurement is running and the on-viola-
tion event is set to trigger out pulse.
Suffix:
<m>
.
1..3
Irrelevant, omit the suffix.
Parameters:
<Delay> Range: 1.8E-6 to 512E-3
Increment: 1E-9
*RST: 1.8E-6
Default unit: s
Usage: Asynchronous command
22.9.21 Actions on trigger
TRIGger<m>:EVENt:BEEP........................................................................................... 1315
TRIGger<m>:EVENt:PRINt........................................................................................... 1315
TRIGger<m>:EVENt:WFMSave.....................................................................................1315
TRIGger<m>:EVENt:RUNexec......................................................................................1315
TRIGger<m>:OUT:ACTion............................................................................................ 1316
