Rohde & Schwarz RTP044 - Runt Search Conditions

Remote control commands
R&S
®
RTP
1488User Manual 1337.9952.02 ─ 12
Usage: Asynchronous command
SEARch:TRIGger:INTerval:WIDTh <SearchName>,<Width>
SEARch:TRIGger:INTerval:WIDTh? <SearchName>
Defines the time between two pulses.
Parameters:
<Width> Range: 100E-12 to 864
Increment: 100E-9
*RST: 5E-9
Default unit: s
Parameters for setting and query:
<SearchName> Search definition
Usage: Asynchronous command
22.15.6 Runt search conditions
SEARch:TRIGger:RUNT:DELTa.....................................................................................1488
SEARch:TRIGger:RUNT:POLarity..................................................................................1488
SEARch:TRIGger:RUNT:RANGe................................................................................... 1489
SEARch:TRIGger:RUNT:WIDTh.................................................................................... 1489
SEARch:TRIGger:LEVel:RUNT:LOWer...........................................................................1490
SEARch:TRIGger:LEVel:RUNT:UPPer........................................................................... 1490
SEARch:TRIGger:RUNT:DELTa <SearchName>,<WidthDelta>
SEARch:TRIGger:RUNT:DELTa? <SearchName>
Defines a range around the given runt width.
Parameters:
<WidthDelta> Range: 100E-12 to 864
Increment: 100E-9
*RST: 100E-12
Default unit: s
Parameters for setting and query:
<SearchName> Search definition
Usage: Asynchronous command
SEARch:TRIGger:RUNT:POLarity <SearchName>,<Polarity>
SEARch:TRIGger:RUNT:POLarity? <SearchName>
Indicates the polarity of a pulse, that is the direction of the first pulse slope.
