Rohde & Schwarz RTP044 - Time Base

Remote control commands
R&S
®
RTP
1188User Manual 1337.9952.02 ─ 12
STOP
Stops the running acquistion.
Usage: Event
Asynchronous command
22.8.2 Time base
TIMebase:SCALe.........................................................................................................1188
TIMebase:RANGe........................................................................................................1189
TIMebase:DIVisions?....................................................................................................1189
TIMebase:HORizontal:POSition.....................................................................................1189
TIMebase:REFerence...................................................................................................1189
TRIGger<m>:OFFSet:LIMited........................................................................................1190
AUToscale................................................................................................................... 1190
ACQuire:POINts:AUTO.................................................................................................1190
ACQuire:POINts:AADJust............................................................................................. 1191
ACQuire:POINts:MAXimum...........................................................................................1191
ACQuire:POINts:ARATe?.............................................................................................. 1191
ACQuire:SRATe........................................................................................................... 1191
ACQuire:SRReal..........................................................................................................1192
ACQuire:RESolution.....................................................................................................1192
ACQuire:POINts[:VALue]...............................................................................................1192
TIMebase:ROLL:ENABle...............................................................................................1193
TIMebase:ROLL:STATe?...............................................................................................1193
TIMebase:ROLL:MTIMe................................................................................................1193
TIMebase:SCALe <TimeScale>
Sets the horizontal scale - the time per division on the x-axis - for all channel and math
waveforms.
The setting accuracy depends on the current resolution (sample rate).
●
No interpolation:
The resolution is an integer multiple of the ADC sample rate.
●
With interpolation:
Any value for the horizontal scale can be set.
Parameters:
<TimeScale> Range: 25E-12 to 10000 (RTO, RTP) | 5000 (RTE)
Increment: 1E-12
*RST: 10E-9
Default unit: s/div
Usage: Asynchronous command
Acquisition and setup
