Search functions
R&S
®
RTP
468User Manual 1337.9952.02 ─ 12
Remote command:
SEARch:RESult:SORT:ASCending on page 1515
Clear results
Clears the search results once and starts a new search.
Remote command:
SEARch:CLEar on page 1481
Auto clear
If "Auto clear" is enabled, the instrument displays the search results of the last acquisi-
tion.
If "Auto clear" is disabled, the first result of each acquisition is listed until the maximum
number of entries in the table is reached.
Show result zoom
If enabled, a zoom window is displayed for the currently selected search result. The
zoom area is indicated in the diagram that displays the source waveform of the search.
Remote command:
SEARch:RESDiagram:SHOW on page 1513
Define result zoom
Opens a dialog to define the reult zoom display settings.
See Chapter 11.4.2, "Display zoom settings", on page 468.
Export results
Opens a dialog to define the export reults.
See Chapter 12.2.4, "Results", on page 495.
11.4.2 Display zoom settings
You can display a zoom window for the currently selected search result. The zoom
area is indicated in the diagram that displays the source waveform of the search.
Show result zoom
If enabled, a zoom window is displayed for the currently selected search result. The
zoom area is indicated in the diagram that displays the source waveform of the search.
Search display presentation
