SWTRigger:HISTory <ApplyZnTrigHistory>
Applies the zone trigger condition to the acquisitions in the history memory during his-
tory replay.
See: "Apply zone trigger to history" on page 252.
Parameters:
<ApplyZnTrigHistory> ON | OFF
*RST: OFF
Usage: Asynchronous command
22.9.23 External trigger input
To control the external trigger signal, the TRPRobe commands are used. The required
commands depend on the used probe type. They work in the same way as the PROBe
commands. For details, see Chapter 22.8.7, "Probes", on page 1206
TRIGger<m>:EXTern:OVERload <Overload>
The query returns the overload status of the external trigger input.
:TRIGger:EXTern:OVERload 0 confirms the information in the message box, it has
same effect as OK.
Suffix:
<m>
.
1..3
Only 1 = A-trigger, 2 | 3 = not available. Can be omitted.
Parameters:
<Overload> ON | OFF
ON | 1
Iindicates an overload of the probe
OFF | 0
In a query: no overlaod.
Ssetting: confirms the information in the message box
*RST: OFF
Usage: Asynchronous command
22.9.24 Acquisition info
ACQuire:CURRent?
Shows the current number of acquisitions that have been acquired.
Return values:
<CurrAcqCnt> Range: 0 to 4294967295
Increment: 1
*RST: 0
