22.20 Pulse source and TDR/TDT analysis (options
R&S RTP-B7/K130)
22.20.1 Pulse source (option R&S RTP-B7)
Some of the commands in the following chapter are asynchronous. An overlapping or
asynchronous command does not automatically finish executing before the next com-
mand starts executing. If overlapping commands must be executed in a defined order,
e.g. to avoid wrong measurement results, they must be serviced sequentially.
To prevent an overlapping execution of commands, one of the commands *OPC,
*OPC? or *WAI can be used after the command or a command set.
For more information, see:
●
www.rohde-schwarz.com/rc-via-scpi, chapter "Command Sequence and Synchro-
nization"
●
Chapter 22.3, "Programming examples", on page 1126
PSRC[:STAT]...............................................................................................................2241
PSRC:OUTPutlow........................................................................................................2241
PSRC:REPRate...........................................................................................................2242
PSRC:DUTYcycle........................................................................................................ 2242
PSRC:CLOCkmode......................................................................................................2242
PSRC:RST..................................................................................................................2242
PSRC[:STAT] <State>
Switches the pulse output on and off.
Parameters:
<State> ON | OFF
*RST: OFF
Usage: Asynchronous command
PSRC:OUTPutlow <OutputLowLevel>
Sets the low level of the output pulse.
Parameters:
<OutputLowLevel> Range: -0.2 to -0.05
Increment: 0.01
*RST: -0.05
Default unit: V
Usage: Asynchronous command
