Remote control commands
R&S
®
RTP
2242User Manual 1337.9952.02 ─ 12
PSRC:REPRate <RepetitionRate>
Sets the pulse frequency, the repetition rate of the pulse.
Parameters:
<RepetitionRate> Available values depend on the selected clock mode:
Locked: 5/10/20/50/100/200/500 Hz, 1/5/10/25/50/100/250 MHz
Free running: 5/10/20/50/100/200/500 Hz, 1/5/10/25/50 MHz
*RST: 1E+6
Default unit: Hz
Usage: Asynchronous command
PSRC:DUTYcycle <DutyCycle>
Sets the duty cycle of the pulse, which is the ratio of the positive pulse width to the
period of the signal.
Parameters:
<DutyCycle> For repetition rates > 5 MHz, the value is fixed at 50 %.
Range: 10 to 90
Increment: 10
*RST: 50
Default unit: %
Usage: Asynchronous command
PSRC:CLOCkmode <ClockMode>
Sets the dependency of the pulse clock on the instrument's reference clock.
Parameters:
<ClockMode> LOCKed | FREerunning
LOCKed
The pulse source is locked to the reference clock of the instru-
ment.
FREerunning
The clock of the pulse source is independent. Deviations of the
system do not affect the pulse clock, and deterministic condi-
tions are avoided.
*RST: FREerunning
Usage: Asynchronous command
PSRC:RST
Resets the pulse source to the default state.
Usage:
Event
Asynchronous command
Pulse source and TDR/TDT analysis (options R&S RTP-B7/K130)
