Protocol analysis
R&S
®
RTP
911User Manual 1337.9952.02 ─ 12
13.23.2 Search on decoded DDR data
Using the search functionality, you can find various events in the decoded data. You
can find the same events that you can trigger on, and even many more, since several
event types can also be combined.
Before you can start the search, you have to configure the bus correctly and acquire
decoded data.
To search on decoded data, set the search source to "SerBus" for the configured proto-
col.
For general information on how to handle the search functionality, see Chapter 11,
"Search functions", on page 448.
If you need information on how to get started with searching for DDR data, see Chap-
ter 13.23.2.3, "Searching for DDR data", on page 914. Otherwise proceed with the
DDR search setup.
13.23.2.1 DDR search setup
Access: [Protocol] > "Shortcuts" tab > "Setup search"
In this dialog, you can define the search type for DDR.
DDR (option R&S
RTP-K91/K93 )
