Remote control commands
R&S
®
RTP
1477User Manual 1337.9952.02 ─ 12
MTESt:EYEMask:HEIGht<m>[:VALue] <MaskTestName>, <value>
Defines the main heigth af all eye mask shapes and the minor height for octagon mask
shapes.
Suffix:
<m>
.
1..2
1 - main width
2 - minor width
Parameters:
<value> Default unit: s
Setting parameters:
<MaskTestName> String with the name of the mask test
Usage: Asynchronous command
MTESt:EYEMask:WIDTh<m>[:VALue] <MaskTestName>, <value>
Defines the main width af all eye mask shapes and the minor width for hexagon and
octagon mask shapes.
Suffix:
<m>
.
1..2
1 - main width
2 - minor width
Parameters:
<value> Default unit: s
Setting parameters:
<MaskTestName> String with the name of the mask test
Usage: Asynchronous command
MTESt:EYEMask:MSKRight <MaskTestName>,<Copy>
MTESt:EYEMask:MSKRight? <MaskTestName>
MTESt:EYEMask:MSKLeft <MaskTestName>,<Copy>
MTESt:EYEMask:MSKLeft? <MaskTestName>
Copies the eye shape to the right and left, respectively.
The distance of the copy is defined using MTESt:EYEMask:HPERiod.
Parameters:
<Copy> ON | OFF
*RST: OFF
Parameters for setting and query:
<MaskTestName> String with the name of the mask test
Usage: Asynchronous command
Mask testing
