Remote control commands
R&S
®
RTP
1499User Manual 1337.9952.02 ─ 12
SEARch:TRIGger:SETHold:CLEVel <SearchName>,<ClockLevel>
SEARch:TRIGger:SETHold:CLEVel? <SearchName>
Sets the voltage level for the clock signal. Both this command and SEARch:TRIGger:
SETHold:CEDGe define the starting point for calculation of the setup and hold time.
Parameters:
<ClockLevel> Range: -10 to 10
Increment: 1E-3
*RST: 0
Default unit: V
Parameters for setting and query:
<SearchName> Search definition
Usage: Asynchronous command
SEARch:TRIGger:SETHold:CSOurce <SearchName>,<ClockSource>
SEARch:TRIGger:SETHold:CSOurce? <SearchName>
Selects the waveform used for the clock signal.
Parameters:
<ClockSource> C1W1 | C1W2 | C1W3 | C2W1 | C2W2 | C2W3 | C3W1 | C3W2 |
C3W3 | C4W1 | C4W2 | C4W3 | M1 | M2 | M3 | M4 | M5 | M6 |
M7 | M8 | R1 | R2 | R3 | R4
Source of the clock signal, see Chapter 22.4.2, "Waveform
parameter", on page 1145
*RST: C1W1
Parameters for setting and query:
<SearchName> Search definition name
Usage: Asynchronous command
SEARch:TRIGger:SETHold:HTIMe <SearchName>,<HoldTime>
SEARch:TRIGger:SETHold:HTIMe? <SearchName>
Sets the minimum time after the clock edge while the data signal must stay steady
above or below the data level.
The hold time can be negative. In this case, the setup time is always positive. The
setup/hold interval starts before the clock edge (setup time) and ends before the clock
edge (hold time). If you change the negative hold time, the setup time is adjusted by
the intrument.
Parameters:
<HoldTime> Range: -99.999E-9 to 0.1
Increment: 1E-9
*RST: 0
Default unit: s
Search
