Remote control commands
R&S
®
RTP
1873User Manual 1337.9952.02 ─ 12
Suffix:
<m>
.
*
Query parameters:
<SearchName>
Return values:
<Stop> Range: -100E+24 to 100E+24
Increment: 100E-12
*RST: 0
Default unit: s
Usage: Query only
SEARch:RESult:DPHY:FRAMe<m>:TYPE? <SearchName>
Returns the type of frame for the selected frame within the search result.
Suffix:
<m>
.
*
Query parameters:
<SearchName>
Return values:
<FrameType> HS_SP | HS_LP | HS_INCOMPLETE | LP_HSREQ | LP_TA |
LP_ESC
HS_SP
High speed short packet frame
HS_LP
High speed long packet frame
HS_INCOMPLETE
Incomplete high speed frame
LP_HSREQ
High speed request frame
LP_TA
Low power lane turnaround frame
LP_ESC
Low power escape mode frame
*RST:
HS_SP
Usage: Query only
SEARch:RESult:DPHY:FRAMe<m>:VCHannel? <SearchName>
Returns the number of virtual channels for the selected frame within the search result.
Suffix:
<m>
.
*
Query parameters:
<SearchName>
Protocols
