Remote control commands
R&S
®
RTP
2204User Manual 1337.9952.02 ─ 12
Parameters:
<DeskewOffset> Range: -200E-9 to 200E-9
Increment: 200E-12
*RST: 0
Default unit: s
BUS<m>:PARallel:BIT<n>:LABel <Label>
Sets a name for the indicated digital channel. The name is displayed in the diagram.
For the parallel bus 1, you can also use DIGital<m>:LABel.
Suffix:
<m>
.
1..4
Selects the parallel bus.
<n> 0..15
Selects the bit of the bus word. Each bit corresponds to a digital
channel.
Parameters:
<Label> String containing the channel name
BUS<m>:PARallel:DATA:FORMat <DataFormat>
Sets the number format for decoded data values on the display for the indicated paral-
lel bus.
It sets also the number representation for remote data transfer with BUS<m>:
PARallel:DATA[:VALues]?.
Suffix:
<m>
.
1..4
Parameters:
<DataFormat> HEX | OCT | BIN | ASCII | ASCii | SIGN | USIG
*RST: HEX
BUS<m>:PARallel:DISPlay:SHDI <ShwDigSigns>
If enabled, the selected digital signals are shown in the diagram. Each channel is dis-
played as a logic signal.
See also: DIGital<m>:DISPlay
Suffix:
<m>
.
1..4
Selects the parallel bus.
Parameters:
<ShwDigSigns> ON | OFF
*RST: OFF
Mixed signal option (MSO, R&S RTP-B1)
