Remote control commands
R&S
®
RTP
2262User Manual 1337.9952.02 ─ 12
ADVJitter<m>:SIGNal:TYPE <SignalType>
Select, if the analyzed signal is a data or clock signal.
Suffix:
<m>
.
1..2
Parameters:
<SignalType> CLOCk | DATNrz
*RST: DATNrz
ADVJitter<m>:SIGNal:SOURce <SourceType>
Selects the source for the advanced jitter analysis.
Suffix:
<m>
.
1..2
Parameters:
<SourceType> C1W1 | C1W2 | C1W3 | C2W1 | C2W2 | C2W3 | C3W1 | C3W2 |
C3W3 | C4W1 | C4W2 | C4W3 | M1 | M2 | M3 | M4 | M5 | M6 |
M7 | M8 | R1 | R2 | R3 | R4 | DIFF1 | DIFF2 | COMMON1 |
COMMON2
ADVJitter<m>:SIGNal:QUICkmeas
Starts a quick advanced jitter analysis.
Suffix:
<m>
.
1..2
Usage: Event
ADVJitter<m>:SIGNal:BITRate <NominalBitRate>
Sets the frequency of the feed forward CDR. It corresponds to the data rate of the data
stream from which the clock is to be recovered.
Suffix:
<m>
.
1..2
Parameters:
<NominalBitRate> Range: 1000 to 10E+9
Increment: 10
*RST: 1E+9
Default unit: bps
ADVJitter<m>:SIGNal:CDRMode <MethodType>
Selects the reference source for the CDR signal, if ADVJitter<m>:SIGNal:
REFSource is set to CDR.
Jitter analysis and clock data recovery
