Remote control commands
R&S
®
RTP
2264User Manual 1337.9952.02 ─ 12
ADVJitter<m>:SIGNal:CLFFactor <Factor>
Sets a clock multiplier factor.
Suffix:
<m>
.
1..2
Parameters:
<Factor> Range: 1 to 100
Increment: 1
*RST: 1
ADVJitter<m>:SIGNal:CFEStimation
Executes an estimation of the signal for the clock offset.
Suffix:
<m>
.
1..2
Usage: Event
Asynchronous command
ADVJitter<m>:SIGNal:CLFRequency <Frequency>
Sets the clock frequency for the explicit clock signal.
Suffix:
<m>
.
1..2
Parameters:
<Frequency> Range: 1000 to 10E+9
Increment: 10
*RST: 1E+9
Default unit: Hz
ADVJitter<m>:SIGNal:CLOFfset <Offset>
Sets a clock offset for the explicit clock signal.
Suffix:
<m>
.
1..2
Parameters:
<Offset> Range: -1000 to 1000
Increment: 0.01
*RST: 0
Default unit: UI
ADVJitter<m>:SIGNal:DATRate?
Displays the calculated data rate of the explicit clock signal.
Jitter analysis and clock data recovery
