The following example shows how to create and display an Expert Extended ACL. This expert ACL
permits all the TCP packets with the source IP address 192.168.4.12 and the source MAC address
001300498272.
Ruijie(config)#expert access-list extended exp-acl
Ruijie(config-exp-nacl)#permit tcp host 192.168.4.12 host 0013.0049.8272
any any
Ruijie(config-exp-nacl)#deny any any any any
Ruijie(config-exp-nacl)#show access-lists
expert access-list extended exp-acl
10 permit tcp host 192.168.4.12 host 0013.0049.8272 any any
20 deny any any any any
Ruijie(config-exp-nacl)#
This example shows how to use the extended IP ACL. The purpose is to permit the host with the IP
address 192.168.4.12 to provide services through the TCP port 100 and apply the ACL to interface
gigabitethernet 1/1. The configuration procedure is as below:
Ruijie(config)# ip access-list extended 102
Ruijie(config-ext-nacl)# permit tcp host 192.168.4.12 eq 100 any
Ruijie(config-ext-nacl)# show access-lists
ip access-list extended 102
10 permit tcp host 192.168.4.12 eq 100 any
Ruijie(config-ext-nacl)#exit
Ruijie(config)#interface gigabitethernet 1/1
Ruijie(config-if)#ip access-group 102 in
Ruijie(config-if)#
This example shows how to use the extended MAC ACL. The purpose is to permit the host with the
MAC address 0013.0049.8272 to send Ethernet frames through the type 100 and apply the ACL to
interface gigabitethernet 1/1. The configuration procedure is as below:
Ruijie(config)#mac access-list extended 702
Ruijie(config-mac-nacl)#permit host 0013.0049.8272 any aarp
Ruijie(config-mac-nacl)#show access-lists
mac access-list extended 702
10 permit host 0013.0049.8272 any aarp 702
Ruijie(config-mac-nacl)#exit
Ruijie(config)#interface gigabitethernet 1/1
Ruijie(config-if)#mac access-group 702 in
This example shows how to use the standard IP ACL. The purpose is to permit the host with the IP
address 192.168.4.12 and apply the ACL to interface gigabitethernet 1/1. The configuration
procedure is as below:
