Ruijie RG-S29 Series User Manual

Command Reference RIP Commands
Mode
Usage Guide
This command is used to display the information about RIP interfaces. If no RIP interface exists, no
information is displayed.
Configuration
Examples
The following example displays the RIP interface information.
Ruijie# show ip rip interface
FastEthernet 0/1 is up, line protocol is up
Routing Protocol: RIP
Receive RIPv2 packets only
Send RIPv2 packets only
Recv RIP packet total: 0
Send RIP packet total: 3
Passive interface: Disabled
Split Horizon with Poisoned Reverse: Enabled
Triggered RIP Enabled:
Retransmit-timer: 5, Retransmit-count: 36
V2 Broadcast: Disabled
Multicast registe: Registed
Interface Summary Rip:
Not Configured
Authentication mode: Text
Authentication key-chain: ripk1
Authentication text-password: ruijie
Default-information: only, metric 5
IP interface address:
192.168.64.100/24, next update due in 14 seconds
2.2.1.1/24, next update due in 24 seconds
neighbor 2.2.1.6, next update due in 3 seconds
neighbor 2.2.1.77, next update due in 13 seconds
2.2.2.57/24, next update due in 16 seconds
Related
Commands
Command
Description
show ip rip
Displays the information of the currently
running routing protocol process.
Platform
Description
N/A
1.33 show ip rip peer
Use this command to show the RIP peer information. RIP records a summary for the RIP routing
