Ruijie RG-S29 Series User Manual

Command Reference QoS Commands
24 3 25 3 26 3 27 3
28 3 29 3 30 3 31 3
32 4 33 4 34 4 35 4
36 4 37 4 38 4 39 4
40 5 41 5 42 5 43 5
44 5 45 5 46 5 47 5
48 6 49 6 50 6 51 6
52 6 53 6 54 6 55 6
56 7 57 7 58 7 59 7
60 7 61 7 62 7 63 7
The fields in the output of this command are described in the following table.
Field
Description
dscp
Indicates the DSCP value.
cos
Indicates the CoS value mapped .
The following example displays the IP-PRE-DSCP mapping.
Ruijie# show mls qos maps ip-prec-dscp
ip-precedence dscp
------------- ----
0 0
1 8
2 16
3 24
4 32
5 40
6 48
7 56
The fields in the output of this command are described in the following table.
Field
Description
ip-precedence
Indicates the IP-PRE value.
dscp
Indicates the DSCP value mapped .
Related
Commands
Command
Description
N/A
N/A
