Command Reference IPv6 Commands
IPv6 address prefix in the format defined in RFC4291. The address
shall be in hex; the fields in the address shall be separated by comma,
and each field shall contain 16 bits.
IPv6 address in the format defined in RFC4291. The address shall be
in hex; the fields in the address shall be separated by comma, and
each field shall contain 16 bits.
Length of the IPv6 prefix, the network address of the IPv6 address.
Note: The prefix length range of the IPv6 address of the interface of
S86 is 0 to 64 or 128 to 128.
The general prefix name. Use the specified general prefix to generate
the interface address.
The value of the sub-prefix bit and the host bit generates the interface
address combining with the general prefix. The value shall be in the
format defined in the RFC4291.
The generated IPV6 address consists of the address prefix and the 64
bit interface ID
Interface configuration mode
When an IPv6 interface is created and the link status is UP, the system will automatically generate a
local IP address for the interface.
The IPv6 address could also be generated using the general prefix. That is, the IPv6 address consists
of the general prefix and the sub-prefix and the host bit. The general prefix could be configured using
the ipv6 general-prefix command or may be learned through the DHCPv6 agent PD (Prefix
Discovery) function (please refer to the DHCPv6 Configuration). Use the sub-bits/prefix-length
parameter of this command to configure the sub-prefix and the host bit.
If no deleted address is specified when using no ipv6 address, all the manually configured
addresses will be deleted.
no ipv6 address ipv6-prefix/prefix-length eui-64 can be used to delete the addresses configured with
ipv6 address ipv6-prefix/prefix-length eui-64.
Ruijie(config-if)# ipv6 address 2001:1::1/64
Ruijie(config-if)# no ipv6 address 2001:1::1/64
Ruijie(config-if)# ipv6 address 2002:1::1/64 eui-64
Ruijie(config-if)# no ipv6 address 2002:1::1/64 eui-64
