Ruijie RG-S29 Series User Manual

Command Reference IPv4/IPv6 REF Commands
Usage Guide
This command is used to specify the source and the destination IP address of the IP packets, and to
display the path of forwarding the current packet with REF
Configuration
Examples
The following example displays the IPv4 REF exact route from 192.168.217.74 to 192.168.13.1.
Ruijie# show ip ref exact-route 192.168.217.74 192.168.13.1
192.168.217.74 --> 192.168.13.1:
id state type rfct chg ip interface linklayer(header
data)
9 resolved forward 1 0 192.168.17.1 GigabitEthernet 0/0 00 25 64 C5 9D
6A 00 D0 F8 98 76 54 08 00
Description of fields:
Field
Description
id
Adjacency ID
state
Adjacency state:
Unresolved
Resolved
type
Adjacency type
Local: local adjacency
Forward: forward adjacency
Discard: discard adjacency
Glean: glean adjacency
Mcast: multicast adjacency
rfct
Reference count of the adjacency
chg
Whether the adjacency is on the changing link.
ip
Adjacency IP address
interface
Interface
linklayer
Layer 2 head
Related
Commands
Command
Description
show ip ref route
Displays all routing information in the current REF module.
Platform
Description
N/A
12.5 show ip ref packet statistics
Use this command to display IPv4 REF packet statistics.
show ip ref packet statistics
Parameter
Parameter
Description
