Ruijie RG-S29 Series

Command Reference NSM Commands
VRF1
Memory: 2000 bytes
Entries: 22,based on route prefixes
Entries: 29,based on route nexthops
NORMAL
ECMP FRR TOTAL
Connected 3 0 0 3
Static 2 1 1 4
RIP 1 2 1 4
OSPF 2 1 1 4
ISIS 1 2 0 3
BGP 2 1 1 4
TOTAL 11 7 4 22
S29 series switch does not support ISIS or BGP. The configuration example is only for
reference.
Field
Description
NORMAL
Type of the table entries. Value:
NORMAL: common routes (not ECMP or FRR);
ECMP: equivalent route;
FRR: fast reroute;
TOTAL: total
Memory
Memory occupied by the table.
Entries
Number of entries (based on prefix, not next-hop)
Connected
Protocol type. Value:
Connected: direct connection;
Static: static;
RIP: RIP;
OSPF: OSPF;
ISIS: ISIS;
BGP: BGP;
TOTAL: total
5.15 show ipv6 redirects
Use this command to display the IPv6 default gateway IP address.
show ipv6 redirects
Parameter
Description
Parameter
Description
N/A
N/A
Defaults
N/A
