Ruijie RG-S29 Series User Manual

Command Reference Protocol-independent Configuration Commands
6.32 set ip tos
Use this command to set the tos of the IP head of the packet matching the rule in the route map
configuration mode. Use the no form of this command to remove the configured tos setting.
set ip tos {<0-15> | max-reliability | max-throughput | min-delay | min-monetary-cost | normal }
no set ip tos
Parameter
Description
Parameter
Description
number
Indicates the TOS value of an IP header with a number, ranging from 0
to 15.
2: max-reliability
4: max-throughput
8: min-delay
1: min-monetary-cost
0: normal
max-reliability |
max-throughput |
min-delay |
min-monetary-cost |
normal
Priority of an IP header.
Defaults
N/A
Command
mode
Route map configuration mode
Usage
guideline
With different TOS values for the IP packet head configured, the IP packets matching the PBR routing
are transmitted with different service qualities.
The TOS value will be specified for the head of the IP packet matched the PBR.
Examples
The following example sets the TOS value of the packet with the source IP address 192.168.217.68
received at the interface FastEthernet 0/0 as 4:
Ruijie(config)#access-list 1 permit 192.168.217.68 0.0.0.0
Ruijie(config)#route-map name
Ruijie(config-route-map)#match ip address 1
Ruijie(config-route-map)#set ip tos 4
Ruijie(config)#interface FastEthernet 0/0
Ruijie(config-if)#ip policy route-map name
Related
commands
Command
Description
match interface
Match the next-hop interface.
match ip address
Match the IP address in the ACL.
