Boards for HiPath 3000
P31003-H3560-S403-54-7620, 09/05
3-70 HiPath 3000 V6.0, HiPath 5000 V6.0, Provisional Service Manual
boards.fm
Central Boards
Installing RGMOD
The ring generator RGMOD is plugged in on the backplane.
● Basic cabinet
When using one or more SLMA2 boards in the basic cabinet, RGMOD must be plugged
into the 10-pin port X214 of the basic cabinet (see Figure 3-25).
Figure 3-25 HiPath 3800 - Connectors and Jacks on the Backplane of the Basic Cabi-
net
X214
