Boards for HiPath 3000
P31003-H3560-S403-54-7620, 09/05
3-118 HiPath 3000 V6.0, HiPath 5000 V6.0, Provisional Service Manual
boards.fm
Peripheral Boards
LED statuses and their meanings
Table 3-47 IVML8 and IVML24 - LED Statuses
LED
Yellow
LED
Green
Meaning Action
During Startup and Initialization
Off Off 1 Boot procedure (lasts approx. 8 - 12 s)
On On 2 LED test (lasts approx. 10 s)
On Off 3 Lockout switch state signaling by yellow
LED (lasts approx. 5 s):
● blocked = On
● free = Off
If necessary, check
whether the board was
deactivated using Hi-
Path 3000 Manager E or
lockout switch.
Off
Flashing
(500/
500 ms)
Off 4 Hard disk test, start of the application (de-
pending on hard disk status, lasts approx.
3- 8minutes)
Off On 5a Standby mode after successful boot
On Off 5b Board locked or board error occurred Check whether board
was deactivated using
HiPath 3000 Manager E
or lockout switch.
During Operation
Off On Idle (no call)
Off Flashing
(500/
500 ms)
At least one active port (call)
Flashing
(500/
500 ms)
Flashing
(500/
500 ms)
Lockout switch activated during a call
On Off Board locked or board error occurred Check whether board
was deactivated using
HiPath 3000 Manager E
or lockout switch.
