HiPath Cordless Office
Power-Related Capacity Limits
● HiPath 3550 and HiPath 3500
The following tables show which telephone configurations do not need an additional power
supply:
– Table 11-4, depending on the number of BS3/1 and BS4 base stations connected to
the central CBCC/CBRC control board.
– Table 11-5, depending on the number of BS3/1 base stations connected to SLC16N
and the number of BS4 base stations connected to SLC16N.
– Table 11-6, depending on the number of BS2/2 base stations connected to SLC16N.
– Table 11-7, depending on the number of BS3/3 base stations connected to SLC16N
and the number of BS4 base stations connected to SLC16N.
If extra telephone configurations are added to these, an additional power supply (by
EPSU2 or EPSU2-R) is needed.
Table 11-4 HiPath 3550, HiPath 3500 - Maximum Number of Corded Telephones De-
pending on the Number of BS3/1 and BS4 Base Stations Connected to
CBCC or CBRC
Number
of BS3/1s and BS4s
connected via
1xU
P0/E
to
CBCC or CBRC
Maximum number of corded telephones
analog telephones
0 1 - 10 11 - 20 21 - 30 31 - 40 41 - 50
optiset E and optiPoint 500 telephones
1 666157534844
2 635954504641
3 605652474339
4 585349454036
5 555147423833
6 534844403531
7 504641373328
