Siemens SINUMERIK Series Function Manual

B3: Distributed systems - 840D sl only
2.3 Examples
Extended Functions
132 Function Manual, 03/2013, 6FC5397-1BP40-3BA1
Table 2- 2 NCUa, position: a, channel: 1, slide: 1
Channel axis name ..._MACHAX
_USED
$MN_
AXCONF_LOGIC_MACH
AX_TAB,
Container, slot
entry (string)
Machine axis name
S4 1 AX1: CT1_SL1 1 1
NC1_AX1
HS1
S3 2 AX2: CT3_SL1 3 1
NC1_AX2
GS1
X1 3 AX3: X1A
Z1 4 AX4: Z1A
Z3 5 AX5: CT4_SL1 4 1
NC1_AX5
ZG1
S1 6 AX6: WZ1A
STN 7 AX7: CT2_SL1 2 1
NC1_AX7
STN1
TRV 11 AX11: TRV
TRH 12 AX12: TRH
x2 *
z2 *
Table 2- 3 NCUa, position: a, channel: 2, slide: 2
Channel axis name ..._MACHAX
_USED
$MN_
AXCONF_LOGIC_MACH
AX_TAB,
Container, slot
entry (string)
Machine axis name
S4 1 AX1: CT1_SL1 1 1
NC1_AX1
HS1
S3 2 AX2: CT3_SL1 3 1
NC1_AX2
GS1
Z3 5 AX5: CT4_SL1 4 1
NC1_AX5
ZG1
STN 7 AX7: CT2_SL1 2 1
NC1_AX7
STN1
X2 8 AX8: X2A
Z2 9 AX9: Z2A
S1 10 AX10: WZ2A
x1 *
z1 *
Note
* due to program coordination via axis positions and 4-axis machining in one position
Entries in the axis container locations should have the following format: "NC1_AX.." with the
meaning NC1 = NCU 1. In the above tables, NCUa is imaged on NC1_..., NCUb on NC2_...
etc.
