B3: Distributed systems - 840D sl only
2.3 Examples
Extended Functions
Function Manual, 03/2013, 6FC5397-1BP40-3BA1
133
Further NCUs
The above listed configuration data must be specified accordingly for NCUb to NCUd.
Please note the following:
● Axes TRA and TRB only exist for NCUa, channel 1.
● The container numbers are maintained for the other NCUs as they were specified for the
individual axes
● The slot numbers are as follows:
NCUb → 2
NCUc → 3
NCUd → 4.
● The machine axis names are as follows:
NCUb → HS2, GS2, ZG2, STN2
NCUc → HS3, GS3, ZG3, STN3
NCUd → HS4, GS4, ZG4, STN4.
Axis container
The information relating to containers given in Table 7-17 and the container entries of the
similarly configured NCUs, NCUb to NCUd, are specified in the following tables, sorted
according to containers and slots, as they have to be set in machine data:
MD12701 $MN_AXCT_AXCONF_ASSIGN_TAB1[slot]
. . .
MD12716 $MN_AXCT_AXCONF_ASSIGN_TAB16[slot]
whereby slots: 1-4 must be set for the 4 positions of a multi-spindle turning machine:
Note
For the machine data entry
$MN_AXC_AXCONF_ASSIGN_TAB
i
[slot]
the values (without decimal point and machine axis name) that are entered under initial
position in the above tables must be set.
