Siemens SINUMERIK Series Function Manual

H1: Manual and handwheel travel
3.4 Handwheel travel in JOG
Extended Functions
Function Manual, 03/2013, 6FC5397-1BP40-3BA1
165
MD20624 $MC_HANDWH_CHAN_STOP_COND NC/PLC interface signal Scope
Bit == 0 Bit == 1
DB11 DBX0.5 (mode group
stop)
Geometry axis / machine
axis
Interruption until NC start Abort
DB11 DBX0.6 (mode group
stop, axes plus spindle)
Geometry axis / machine
axis
Interruption until NC start Abort
DB21, ... DBX7.3 (NC Stop) Geometry axis / machine
axis
Interruption until NC start Abort
DB21, ... DBX7.4 (NC stop,
axes plus spindle)
Geometry axis / machine
axis
Interruption until NC start Abort
DB21, ... DBX6.0 (feedrate
disable)
Geometry axis / machine
axis
Interruption Abort
DB21, ... DBB4 (feedrate
override)
DB31, ... DBX4.5 (rapid
traverse override)
Geometry axes Override == 0: Interruption if
rapid traverse override is not
active
Override == 0: Abort if rapid
traverse override is not
active
DB21, ... DBB5 (rapid
traverse override)
DB31, ... DBX4.5 (rapid
traverse override)
Geometry axes Rapid traverse override == 0:
Interruption if rapid traverse
override is active
Rapid traverse override == 0:
Abort if rapid traverse
override is active
DB21, ... DBX12/16/20.3
(geometry axis 1/2/3:
Feedrate stop)
Geometry axis Interruption Abort
MD32084 $MC_HANDWH_CHAN_STOP_COND NC/PLC interface signal Scope
Bit == 0 Bit == 1
DB31, ... DBB0 (axial
feedrate override)
Machine axis, not spindle Override == 0: Interruption Override == 0: Abort
DB31, ... DBB19 (spindle
override)
Spindle Override == 0: Interruption Override == 0: Abort
DB31, ... DBX4.3 (feedrate
stop / spindle stop)
Geometry axis / machine
axis
Interruption Abort
DB31, ... DBX2.3 (clamping
in progress)
Geometry axis / machine
axis
No effect Abort
DB31, ... DBX2.1 (control
system enable)
Geometry axis / machine
axis
Interruption Abort
DB31, ... DBX21.7 (pulse
enable)
Geometry axis / machine
axis
Interruption Abort
Note
Removal of the "Controller enable" and "Pulse enable" during traversing results in a rapid
stop of the axis and a reset alarm.
